Aeronautical Chart User’s Guide – 2024 – Mini size

Aeronautical Chart

Users’ Guide

Dated 5 Sept 2024

Mini size: great to put in your pocket or airplane side pocket.

The definitive FAA reference source for understanding and interpretation of all aviation charts.

The Federal Aviation Administration (FAA) publishes aeronautical charts for each stage of visual (VFR) and instrument (IFR) flight, including training, planning, departure, enroute (low and high altitude), approach, and taxiing. This guide is an excellent reference for novice and experienced pilots alike, as well as for international pilots becoming familiar with U.S. charts. This 14th edition of the Aeronautical Chart User’s Guide is the definitive learning aid, reference document, and introduction to the wealth of information provided on FAA charts and in chart navigation publications.

Produced by the FAA’s Aeronautical Information Services branch, it explains all the symbology for FAA sectional, terminal area, flyway planning, helicopter route, enroute low- and high-altitude, and oceanic route charts, as well as standard terminal arrival routes, standard instrument departures, and instrument approach procedures. Also includes chart legends, airspace classification tables, and is illustrated throughout with full-color graphics.

Full COLOR

This book is a “mini” (half the size of a regular piece of paper) size – A popular size to carry anywhere (briefcase, large pocket, purse) but the print is large enough for easy reading. Coil binding is used to allow for easy page flipping with no binding.

This website also has this book in “BIG” size (the size of a regular sheet of paper)

The covers are laminated for weather protection with black and white inside printing.
